InfiRay Outdoor BOLT TH50C V2 640×512 Thermal Night Vision Scope


The iRay BOLT TH50C V2 is a great scope. Don’t say anything you don’t want to be heard because it’s got a great microphone. You feel like you’re shooting through a wide-screen TV with this scope’s great picture quality. The sensor is great and the eyepiece resolution is even higher. This scope is as good a product as there is on the market.



The BOLT-C Series expands on the success of the BOLT with the addition of our industry leading 12 μm 640×512 Micro II sensor, 2560×2560 Micro-OLED HD display and Shutterless Calibration feature. The BOLT-C Series maintains the traditional look and flexibility of a 30mm ring mounting interface, while its proven combination of a manual focus lens, dual battery design and tactile control turret work in tandem with its pixel-dense display to provide an improved viewing experience and unmatched level of precision to you next hunt.

Features Include:

  • High Resolution 640X512 Sensor
  • Rugged Aircraft Aluminum Housing
  • Internal Recording
  • Wifi connectivity with InfiRay Outdoor App
  • 8 Hour internal battery
  • 18500 Removable/Rechargeable Battery Capable (4hrs)
  • Full Circular Display
  • Tactile Turret Adjustment
  • 30mm Mounting versatility
BOLT-C SERIES BOLT-C 640 50mm BOLT-C 640 35mm
Resolution 640×512
Pixel Size 12 μm
Framerate 50hz
Image Processing MATRIX III
Core iRay Micro II 640
Objective Lens 50 mm f/1.1 35mm f/1.1
Magnification 3.5X 2.5X
Digital Zoom 4X
HFOV 8.8° x 7.0° 12.5° x 10.0°
Detection Range 2400 Yards 1750 Yards
Display Taype Micro OLED
Display Resolution 2560×2560
Imaging Modes White Hot, Black Hot, Red Hot, Color, Highlight
Reticle Types 7 (2 Dynamic, 5 Static)
Reticle Colors Black, White, Red, Green
Mounting System 30MM Rings (included)
P.I.P. Yes
Rangefinder Stadiametric
Eye Relief 50mm
Dipoter Range -5 – +5
Onboard Recording Video and Image
Wireless Connectivity Video/Image via App.
Data/Power Connector USB-C
Power Supply Built-in battery pack, 8 Hours
18500 battery (+2 Hours), 18650 battery (+3.5 Hours)
Start Up Time < 10 Seconds, Instant from Standby
Size 14.56″~3.34″~2.95”
Weight 33.15 Oz 32.09 Oz
Warranty 5 Years
Housing Material T-6061 Aluminum
Ingress Protection IP67
Operation Temp -4°F~122°F
Max. Recoil 1000 g/s. (300 Win./7mm Mag)
